Fixed Earthing Terminal

The Fixed Earthing Terminal (ARK-ES1) is an ARK structural earthing component manufactured by DFMHUB in India. It provides a defined connection point between the concealed structural earthing network and an accessible bonding or earthing conductor. It is intended for engineered earthing and bonding systems in commercial buildings, industries, data centres, infrastructure, high-rise developments and solar projects. A catalogue code gives procurement and site teams a controlled item to coordinate with the BOQ and approved drawings.

An embedded terminal is safety-relevant because it becomes the accessible interface to work that will later be hidden inside concrete. Its position, thread, face, tail arrangement and connection to reinforcement must be defined before shuttering. A misplaced or contaminated terminal can create rework, inaccessible joints or uncertainty during commissioning, even when the terminal itself is correctly manufactured.

DFMHUB supports Fixed Earthing Terminal (ARK-EF1) with product identification, dimensional review, material/finish confirmation and order-specific documentation as agreed in the quotation or approved submittal. The component must be selected as part of the complete engineered system, not by product code alone.

Installation method
1. Verify Fixed Earthing Terminal (ARK-EF1) against the approved drawing, BOQ, mating components, substrate and environmental exposure.
2. Install at the approved location using the project drawing, compatible hardware and method statement; inspect dimensions, fixing and continuity as applicable.
3. Use only compatible hardware, connectors, anchors, weld details or transition arrangements. Apply the manufacturer-declared torque where a bolted joint requires it; do not guess torque values on site.
4. Inspect alignment, fixing, contact condition, corrosion compatibility and accessibility. Complete continuity or system testing where specified and record concealed work before covering or concrete placement.


RFQ information required For an accurate offer for Fixed Earthing Terminal (ARK-EF1), share quantity, required dimensions and material/finish, mating conductor or rebar sizes, approved drawing/specification, project location and delivery PIN code, inspection/test documentation, packing requirements and required delivery date.
